此产品已经停止销售，请与我们联系获得更多帮助。
Specifications
All specifications are guaranteed unless noted otherwise. All specifications apply to all models unless noted otherwise.
Model overview
| Characteristic | P7350 | P7330 | P6330 |
|---|---|---|---|
| Rise Time | |||
| Bandwidth | 5.0 GHz | 3.5 GHz | 3.5 GHz |
| Attenuation | 6.25x | 5x | 5x |
| Differential Input C | |||
| Differential Input Resistance | 100 kΩ | 100 kΩ | 100 kΩ |
| Differential Input Range | ±2.5 V (20 °C to 30 °C) | ±2 V (20 °C to 30 °C) | ±2 V (20 °C to 30 °C) |
| Common Mode Input Range | +6.25 V to -5 V | +5 V to -4 V | +5 V to -4 V |
| Max Voltage (nondestruct) | ±15 V (DC + peak AC) | ±15 V (DC + peak AC) | ±15 V (DC + peak AC) |
| CMRR | >55 dB at 1 MHz (typical) | >60 dB at 1 MHz (typical) | >60 dB at 1 MHz (typical) |
| Noise | Approx. 46 nV/root Hz | Approx. 35 nV/root Hz | Approx. 35 nV/root Hz |
| Interface | TekConnect | TekConnect | TEKPROBE II BNC |
| Cable Length | 1.3 m | 1.3 m | 1.3 m |
